Lamp power
400W
colour
RGBW/RGBAL ( 400W)
Led lamp beads
Imported lamp beads
Rated voltage
AC100-240V
Total power consumption
520W
Beam angle
19 ° /26 ° /36 ° /50 ° ( optional )
life
More than 50,000 hours
Dimming curve
4 species
Dimming mode
Frequency optional 500hz-25000hz
Strobe
1-25 times / sec
focal length
Can be adjusted manually
technology
High quality optical system, glass reflector
Body
Die-cast aluminum
Touch screen
LCD panel with touch screen
Control System
RDM protocol / DMX512, self-propelled mode, master-slave mode
DMX channel
4/7CH (RGBW); 5/8CH (RGBAL)
Operating temperature
-30~40 °C
waterproof level
IP20
cooling system
Silent fan
net weight
10.5kgs
Gross weight
12kgs
Package dimensions
70x30x31cm (1 th 1 loaded )
