YF-LED1525

rated power
25 Ke 15W Four high-brightness light beads

Electronic zoom angle
6.5°-60°

Input voltage
AC 90V-260V , 50 / 60HZ

rated power
484W

source
19pcs15W high luminance 4 together 1 of LED

ZOOM
3 zoom motor work together with the same step

ArtNet channel
75/100 channel

DMX channel
13/24/88/113 channel

control
DMX512 /ArtNet/ RDM

Horizontal and vertical
X/Y axis infinite rotation

Fixed lock
Horizontal / vertical lock

display
2.4 inch LCD color LCD display, 180 degree rotatable
Signal input / output
Three-core and five-core card socket

Power outlet
PowerCon input

Protection level
IP20

Fixed bracket system
Two Omega 1/4 swivel brackets are designed using standard fixtures

Dimming
0-100% electronic linear dimming, super smooth and flicker free; optional two dimming modes ( delay or no delay )

protection
Automatic control of cooling fan speed with over-temperature protection
Each lamp bead can be controlled separately, zoom, dye and beam effect freely switch, single control can display numbers and letters, arrows and other patterns
ArtNet , RDM Control Protocol

Net weight
22kg

hairweight
26kg

Carton size
510*410*630mm

Air box one size
860*440*830mm
